• • Multifunctional

  Similar to the MultiPlus, the Quattro is also a combined inverter and charger. Additionally, it can accept two AC inputs and automatically connect to the active source. Its many features include a true sine wave inverter, adaptive charging, hybrid PowerAssist technology plus multiple systems integration features such as three or split-phase operation and parallel operation.

  • Two AC Inputs & two AC Outputs

  The Quattro can be connected to two independent AC sources, for example, shore-side power and a generator, or two generators. The Quattro will automatically connect to the active source. The main output has no-break functionality. In the event of a grid failure, or shore or generator power being disconnected, the Quattro takes over the supply to the connected loads. This happens so fast (less than 20 milliseconds) that computers and other electronic equipment will continue to operate without disruption. The second output is life only when AC is available on one of the inputs of the Quattro. Loads that should not discharge the battery, such as air-conditioning or a water heater can be connected to this output.

  • Unique PowerAssist feature

  The Quattro will prevent the overload of a limited AC source, such as a generator or shore power connection. First, battery charging will automatically be reduced when otherwise an overload would occur. The second level will boost the output of a generator or shoreside supply with power taken from the battery.

  • Virtually unlimited power thanks to parallel operation

  Up to 6 Quattros can operate in parallel to achieve higher power output. Three-phase or split-phase operation is also possible. Please check our datasheets to see which models have parallel, three-phase, and split-phase capabilities.

  • Remote Monitoring and Control

  Monitor and control your Quattro and system or systems locally (LAN) or remotely via the internet from anywhere in the world, using the free VRM app and free VRM portal website. Access can be from a phone, tablet, laptop, or PC for multiple operating systems. There is no end to the level of control, via the required Color Control GX or Venus GX, from adjusting your Quattro to setting a Geofence for-hire vehicles and more…

Revolutionary Energy Storage with BYD Battery-Box LV5.0 & LV5.0+

The BYD Battery-Box LV5.0 (and its upgraded version, LV5.0+) is a cutting-edge, low-voltage battery solution designed to optimize solar energy usage for both residential and commercial applications. Featuring a reliable Lithium Iron Phosphate (LiFePO₄) chemistry, the system not only prioritizes safety but also provides 100% usable capacity, ensuring maximum energy storage efficiency.

Key Features and Technical Specifications

This highly modular energy storage solution offers exceptional scalability and performance:

Usable Energy: 5.12 kWh per unit
Nominal Voltage: 51.2 V
Battery Chemistry: Lithium Iron Phosphate (LFP)
Efficiency: ≥ 95% round-trip
Scalability: Supports up to 32 units in parallel (total of 163.84 kWh)
Warranty: 10 years
Dimensions and Weight: Compact at 195 x 625 x 285 mm and ~45 kg

These specifications allow for easy configuration and seamless integration into various setups, making it ideal for diverse energy-storage needs.

Why Choose the BYD Battery-Box LV5.0 & LV5.0+

Superior Safety: Built with the same LFP cell technology proven in BYD electric vehicles, ensuring durability and robust performance.
Scalability and Flexibility: Start small with a single 5.12 kWh unit and expand effortlessly by stacking or paralleling units to match future energy demands.
High Efficiency: Offers 100% depth of discharge (DoD), allowing you to store and optimize your daily solar power usage.
Wide Compatibility: Features intelligent management systems that support one-click auto-configuration with leading inverter brands like Victron, SMA, and GoodWe.

Ideal Applications

The BYD Battery-Box LV5.0 & LV5.0+ excels in a wide range of use cases, including:

Residential and Commercial Solar Storage: Perfect for on-grid self-consumption, backup power during outages, or fully off-grid setups.
Scalable Systems: Accommodates future energy capacity expansion without requiring complex upgrades to the existing infrastructure.

Whether you’re looking to enhance your energy independence or future-proof your energy solutions, the BYD Battery-Box LV5.0 & LV5.0+ delivers unparalleled performance, flexibility, and peace of mind in a rapidly evolving energy landscape.

DEYE SE-G5.3 5.32 kWh 51.2 V 104 Ah LV LiFePO4 Battery
Safer
Cobalt Free Lithium Iron Phosphate (LFP) Battery: Safety and
long lifespan, high efficiency and high power density.
Intelligent BMS, providing complete protection.
◆ Reliable
Support high discharge power. IP20, natural cooling, wide
temperature range: -20℃ to 55℃.
◆ Flexible
Modular design, easy to expand, Max. 64 units in parallel,
Max. capacity of 340kWh.
Suited to residential and commercial applications for increasing
the self-consumption ratio.
◆ Convenient
Battery module auto networking, easy maintenance, support
remotely monitoring and upgrade, support USB drive upgrade
the firmware.
◆ Eco-Friendly
Use environmental protection materials, the whole module
non-toxic, pollution-free.

MultiPlus-II GX 48-5000-70-50 Inverter/Charger – Revolutionary Power Control at Your Fingertips

The MultiPlus-II GX 48-5000-70-50 Inverter/Charger is a state-of-the-art solution for managing grid-connected, off-grid, or remote power installations with ease. Equipped with built-in device networking, it communicates seamlessly with solar chargers, batteries, and other critical devices to deliver an optimized and intelligent energy experience. From controlling load limits to supplementing limited grid-power availability using battery power, this device offers unparalleled utility.

Unmatched Scalability and Versatile Configuration

What sets the MultiPlus-II GX apart is its ability to adapt to your power demands. Designed to scale, it supports parallel operation, allowing users to increase both power output and battery charge rates. Furthermore, it can be configured for a three-phase supply, ensuring compatibility with diverse energy infrastructures while remaining flexible enough to meet varying operational requirements.

Smart Controls and Remote Monitoring

The advanced features of the MultiPlus-II GX put convenience and control in your hands. Manage uninterrupted power supply, adjust device settings, and even monitor operations remotely—all through your smartphone or smart device. This product ensures you remain in charge of your energy environment, delivering reliability and peace of mind wherever and whenever you need it most.
