The latest, most advanced features on the industry’s most trusted and proven platform—that’s the essence of OutBack’s new FXR Series of Grid/Hybrid inverter/chargers. Capable of off-grid or grid-connected operation in a single model, the FXR Grid/Hybrid inverter/chargers provide system designers with unprecedented flexibility and compatibility for nearly any power conversion scenario.

The new FXR features and technologies on the acclaimed FX platform include:

• Both off-grid and grid-tied functionality in one unit
• Seven programmable modes, including GridZero and Support Mode and built-in networked communications
• Advanced Battery Charging (ABC) with expanded charging voltages and time parameters, enabling system designers to accommodate the specific charging profiles and algorithms of new and emerging energy storage technologies including Lithium Ion, Aqueous Ion and Flow chemistry batteries
• Easy system upgradability in the field

FXR inverter/chargers can be paired with a MATE3s remote to add OPTICS RE to remotely monitor and control system performance from any location. Available in power ranges from 2000W-3600W, multiple units may be stacked and connected with other OutBack Power electronics for more seamless system integration and the ability to function in a wide variety of applications, and system sizes. Up to nine inverters can be combined in a 3-phase system with the 12V, 24V or 48V models, and up to 36kW in a grid-tied 24V or 48V system. The exclusive modular system architecture means that increased power output is just an additional FXR inverter/charger away.

Available in sealed or vented units with NEMA type 1 die-cast aluminum chassis designed to operate in the harshest environmental conditions such as high temperatures, humidity or corrosive salt air, the FXR’s continue in OutBack’s tradition of absolute dependability in mission critical installations no matter how harsh or challenging the conditions.

Features:

• Dimensions (LxWxH): 16.25 × 8.25 × 12 inches
• Weight: 28 kg
• Single-phase, 230V Sinewave Output
• Programmable for Seven Different Modes with Generator Assist
• Modular, Stackable Design for up to Nine Inverters in Three-phase and 10 Inverters in Grid-tied
• Up to 93% Operating Efficiency
• Field Upgradable Software
• Standard 5-Year Warranty with Optional 10-Year Upgrade

Mechanical Characteristics

• Solar Cell: Monocrystalline silicon 182 mm
• No. of Cells: 144 (6 × 24)
• Dimensions: 2278 × 1134 × 35 mm (89.7 × 44.6 × 1.4 inches)
• Weight: 27.5 kgs (60.6 lbs.)
• Front Glass: 3.2 mm (0.126 inches) fully tempered glass
• Output Cables: 4.0 mm2, (-) 350 mm (+) 160 mm in length or customized length
• Junction Box: IP68 rated (3 bypass diodes)
• Operating Module Temperature: -40 °C to +85 °C
• Maximum System Voltage: 1500 V DC (IEC)
• Maximum Series Fuse Rating: 25 A
• Power Tolerance: 0/+5 Wc

Electrical Characteristics

• Module Type: STP555S-C72/Vmh
• Testing Condition: STC
• Maximum Power (Pmax/W): 555
• Optimum Operating Voltage (Vmp/V): 42.24
• Optimum Operating Current (Imp/A): 13.14
• Open Circuit Voltage (Voc/V): 50.07
• Short Circuit Current (Isc/A): 14.07
• Module Efficiency (%): 21.5

SUN2000-100KTL-M2 Smart PV Controller

The HUAWEI SUN2000-100KTL-M2 Smart PV Controller is your gateway to efficient, sustainable energy solutions. Designed to convert DC power from photovoltaic (PV) strings into AC power to feed into the grid, this premium solar inverter offers unmatched technology and reliability. By integrating this advanced controller into your energy system, you can significantly optimize efficiency and lower operational costs while contributing towards a greener planet.

Advanced Technology for Superior Performance

The SUN2000-100KTL-M2 boasts a range of innovative features that set it apart. With a maximum efficiency rate of 98.8% (@480V) and ten independent maximum power point tracking (MPPT) circuits, the system optimizes energy conversion under varying conditions. Supported by 20 PV string inputs and flexible string configurations, it ensures seamless energy management for large-scale PV plants and commercial distributed systems. Its smart self-learning capabilities automatically detect PV module failures and optimize working conditions for long-lasting performance.

Optimized Maintenance and Communication

This PV controller is built with smart diagnostic tools like I-V curve analysis, allowing timely identification and resolution of potential risks or faults, enhancing plant operation and maintenance quality. The MBUS networking feature leverages existing power lines for communication, eliminating the need for additional cables and enhancing reliability. Additionally, the embedded DC and AC surge protection devices, coupled with a residual current monitoring unit, provide robust safeguards to ensure safe and reliable operations.

Why Choose the HUAWEI SUN2000-100KTL-M2?

The SUN2000 is engineered for scalability and maximum efficiency, catering to the needs of commercial grid-tied systems and large-scale plants. With its smart air-cooling mechanism that adjusts fan speed based on ambient conditions, the design ensures extended service life and reduced maintenance needs. By detecting anomalies early and adapting dynamically, this system guarantees hassle-free energy management tailored to your needs.

Future-proof your energy infrastructure with the HUAWEI SUN2000-100KTL-M2, an innovative PV controller designed for performance, sustainability, and efficiency.
