Solar Panel Tile Roof Hook/Anchor – Durable and Reliable Solar Mounting Solution

The Solar Panel Tile Roof Hook is expertly designed to provide a robust and dependable solution for mounting solar panels securely on tiled roofs. This premium-quality L-Foot Solar Panel Mounting Hook ensures stability and durability, making it a must-have for solar panel installations that demand both safety and efficiency.

Enhanced Compatibility and Ease of Installation

Engineered for versatility, this solar roof hook is compatible with a wide range of tile roof types, allowing seamless integration into your installation projects. Featuring 12 M6 self-tightening screws, the product ensures a straightforward installation process while eliminating the need for additional fastening tools. Its precise construction saves time and effort, making it ideal for professional installers and DIY enthusiasts.

Premium Quality for Long-Lasting Performance

Constructed from high-quality materials, the Solar Tile Roof Hook is built to withstand various weather conditions, providing a long-lasting and reliable foundation for your solar energy system. Whether you’re installing panels in residential or commercial settings, this mounting hook guarantees a secure and efficient setup, reinforcing the structural integrity of your solar array.

Higher yields / Safe & Reliable / Smart / User-friendly

SUN-80K-SG02HP3-EU-EM6 is a brand new three-phase hybrid inverter with a high-voltage battery, ensuring the system is safe and reliable. With a compact design and high-power density, this series supports a 1.3 DC/AC ratio, saving device investment. It supports a three-phase unbalanced output, extending the application scenarios. Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remote control, and x1 DRM port, which makes the system smart and flexible.

It is equipped with RS485 / CAN port for battery communication.

Remotely shutdown function

Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remote shutdown immediately when an accident occurs. Setting parameters and FW updates remotely, which makes PV plant O&M easier.

Technical Specifications

Battery Input Data

• Model: SUN-80K-SG02HP3-EU-EM6
• Battery Type: Lithium-ion
• Battery Voltage Range (V): 160-1000
• Max. Charging Current (A): 80+80
• Max. Discharging Current (A): 80+80
• Charging Strategy for Li-ion Battery: Self-adaption to BMS
• Number of Battery Input: 2

PV String Input Data

• Max. PV Access Power (W): 160000
• Max. PV Input Power (W): 128000
• Max. PV Input Voltage (V): 1000
• Start-up Voltage (V): 180
• MPPT Voltage Range (V): 150-850
• Rated PV Input Voltage (V): 650
• Max. Operating PV Input Current (A): 36+36+36+36+36+36
• Max. Input Short-Circuit Current (A): 54+54+54+54+54+54
• No. of MPP Trackers/
  No. of Strings MPP Tracker: 6/2+2+2+2+2+2

AC Input/Output Data

• Rated AC Input/Output Active Power (W): 80000
• Max. AC Input/Output Apparent Power (VA): 88000
• Rated AC Input/Output Current (A): 121.3/115.9
• Max. AC Input/Output Current (A): 133.4/127.6
• Max. Continuous AC Passthrough (grid to load) (A): 200
• Peak Power (off-grid) (W): 1.5 times of rated power, 10s
• Power Factor Adjustment Range: 0.8 leading to 0.8 lagging
• Rated Input/Output Voltage/Range (V): 220/380V, 230/400V 0.85Un-1.1Un
• Rated Input/Output Grid Frequency/Range (Hz): 50/45-55, 60/55-65
• Grid Connection Form: 3L+N+PE
• Total Current Harmonic Distortion THDi: <3% (of nominal power)
• DC Injection Current: <0.5% In

Efficiency

• Max. Efficiency: 97.60%
• Euro Efficiency: 97.0%
• MPPT Efficiency: >99%
